Question: The block of ice (temperature 0°C)

The block of ice (temperature 0°C) shown in Figure P9.53 is drawn over a level surface lubricated by a layer of water 0.10 mm thick. Determine the magnitude of the force F( needed to pull the block with a constant speed of 0.50 m/s. At 0°C, the viscosity of water has the value (( = 1.79 x 10-3 N · s/m2. Figure P9.53:
The block of ice (temperature 0°C) shown in Figure P9.53 is drawn over a level surface lubricated by a layer of water 0.10 mm thick. Determine the magnitude of the force F( needed to pull the block with a constant speed of 0.50 m/s. At 0°C, the viscosity of water has the value (( = 1.79 x 10-3 N · s/m2.

Figure P9.53:
